Features & Specs
- 7,500-pound lifting capacity
- Two different lifting heights to choose from
- Electric / hydraulic power system
- Internal anti-sway slider blocks in each column
- Both models feature heavy-duty 3/8″ aircraft cable
- Multi-position safety locks in each column
- Runways include rail-kit for optional accessories
- Single hydraulic cylinder underneath runway
- Over-sized self-lubricating cable rollers
- Rugged 1-1/4″ roller axles
- Adjustable lock ladders
- Push-button pneumatic safety release
- Durable powder coat finish
Capacity
Lifting Capacity*
7 500 lbs. (3 402 kg)
*Max Capacity / Front Axle
3 750 lbs. (1 701 kg)
*Max Capacity / Rear Axle
3 750 lbs. (1 701 kg)
Rise
A – Min. Runway Height:
5″ (127 mm)
B – Max. Rise:
82″ (2 083 mm)
C – Max. Lifting Height:
87″ (2 210 mm)
Time to Full Rise:
55 seconds
Outside Dimensions
D – Overall Width:
132″ (3 353 mm)
E – Outside Length:
198″ (5 029 mm)
F – Overall Length:
224″ (5 690 mm)
G – Height of Columns:
100″ (2 540 mm)
Inside Dimensions
H – Width Between Columns:
122″ (3 099 mm)
I – Drive-Thru Clearance:
108,5″ (2 756 mm)
Runways
J – Runway Width:
19″ (483 mm)
K – Length of Runways:
188,5″ (4 788 mm)
L – Width Between Runways:
49,5″ (1 257 mm) or 69,5″ (1 765 mm)
M – Runway Centerline:
68,5″ (1 740 mm) or 88,5″ (2 248 mm)
N – Outside Edge of Runways:
87,5″ (2 223 mm) or 107,5″ (2 731 mm)
Minimum Wheelbase
Rated Capacity:
135″ (3 429 mm)
75% Capacity:
115″ (2 921 mm)
50% Capacity:
95″ (2 413 mm)
25% Capacity:
80″ (2 032 mm)
Locking
Locking Positions:
15
Lock Spacing:
Every 4″ (102 mm)
Power Unit
Motor:
220 VAC / 60 Hz / 1 Ph
Noise:
45 dB
Shipping
Weight:
1,980 lbs. (898.1 kg)
Dimensions:
190” x 22” x 39” (4,826 mm x 558 mm x 990 mm)
